Welding Symbols Explained: Complete Chart (AWS A2.4)

A welding symbol is a compact instruction set: which joint, which weld type, what size, what length, which face, and whether the work happens in the shop or on site. Read one element wrong and the weld lands on the wrong side, and the error shows up at inspection rather than at the machine. This guide covers the full AWS A2.4 symbol set, the ISO 2553 equivalents, fillet sizing by thickness, and a reading method for the next drawing on your desk.

What Is the Difference Between a Weld Symbol and a Welding Symbol?

A weld symbol is the shape that names the weld type, such as the triangle used for a fillet. A welding symbol is the complete assembly: arrow, reference line, weld symbol, dimensions, and tail. The weld symbol is one part of the welding symbol, which also fixes side, size, length, and process.

Drawings use “welding symbol” for the whole callout; shop talk shortens it to “weld symbol.” The distinction matters when you check a drawing against a WPS or a purchasing spec, because the weld type is only one line of information. Everything around it fixes where the weld goes, how much of it is required, and who is responsible for making it.

One symbol can carry two welds. The same basic symbol above and below the reference line means both faces are welded. A circle joining the arrow and the reference line means the weld runs the full perimeter. Reading the assembly rather than the shape is the difference between a correct bracket and a rework ticket.

What Are the Parts of a Welding Symbol?

A complete welding symbol has five mandatory parts (arrow, reference line, weld symbol, size, length) and up to seven optional ones (pitch, groove angle, root opening, contour, all-around, field weld, tail). Each element has a fixed position, so a missing element means the drawing has not specified that variable.

The arrow-side rule causes more scrap than any other element. The arrow tip touches one face, and that face is the arrow side: a symbol under the reference line applies to it, while a symbol over the line applies to the opposite face, which on a T-joint is the back of the vertical member. A welder who reads “fillet here” without checking the side can lay a sound weld on the wrong face.

ISO 2553 system A doubles the reference line instead: solid for the arrow side, dashed for the other side. System B uses a single line with the symbol above or below, closer to the AWS layout. Two seconds spent looking at the reference line tells you which convention the drawing follows.

What Are the Basic Weld Symbols in AWS A2.4?

AWS A2.4 defines four weld families (groove, fillet, plug and slot, resistance) plus stud and supplementary symbols, roughly twenty marks in total. The shape tells the welder what to do at the joint; the dimensions around it tell the welder how big and how long. Groove marks need edge preparation, fillet marks do not.

Fillet welds dominate structural and sheet metal work because the corner already forms the joint, so no edge preparation is needed. Groove welds appear where load has to pass through the full section, and they cost more because the edge is cut, beveled, and fitted before the arc starts. The symbol set does not change with the process; the tail names it. For how GMAW, GTAW, FCAW, and SAW differ in deposition rate and position limits, see types of welding.

How Do You Read a Welding Symbol Step by Step?

Read position first, then dimensions, then references: arrow tip to the joint, weld symbol above or below the line, size at the left, length and pitch at the right, groove details inside the symbol, then the tail. That order matches how the job is set up and prevents applying a size to the wrong side.

1. Arrow tip. It touches the joint to be welded, and that face is the arrow side.
2. Reference line. Symbol below means arrow side, symbol above means the other side.
3. Family. Triangle is a fillet, V or half-V is a groove, circle is spot or seam, rectangle is plug or slot.
4. Size. Leg for a fillet, penetration depth for a groove, nugget diameter for a spot, diameter for a stud.
5. Length and pitch. One number is the length; two numbers separated by a hyphen are length then pitch.
6. Groove detail. Included angle, root opening, root face, and groove radius on U and J preparations.
7. Modifiers. Circle for all around, flag for field weld, contour mark for a flat, convex, or concave face.
8. Tail. Process or WPS reference. An empty tail means the process is in the drawing notes.

Worked example 1: arrow-side fillet

A right triangle below the reference line, 6 at its left, 200 at its right, GMAW in the tail. Read it as a 6 mm leg fillet on the arrow side, 200 mm long, gas metal arc welded. Move the triangle above the line and the weld goes on the far face. Join the arrow and reference line with a circle and the length is normally dropped, because the weld then runs the full perimeter.

Another pattern worth knowing by sight: a triangle above the line and a triangle below it, 5 at the left, 50-150 at the right. That is a 5 mm fillet on both faces, 50 mm long on 150 mm centers. Chain or staggered spacing has to come from a note, because the symbol carries pitch but not the offset.

Worked example 2: full-penetration tube joint

A V below the line, 60 degrees beside it, a 2 mm root opening inside, a circle and a flag at the junction, a flat contour mark on top, GTAW in the tail. Read it as a single V groove on the arrow side, 60 degree included angle, 2 mm root gap, complete joint penetration because no size appears, all around, on site, finished flat, gas tungsten arc welded. The flat contour means the cap is dressed flush, which adds an operation to the routing.

What Do Groove Details and Supplementary Symbols Control?

Groove details set the shape of the joint preparation: included angle, root opening, root face, and groove radius. Supplementary symbols add the finish requirement, the all-around or field condition, and backing or insert data. Together they decide how much metal goes in and whether the root is guaranteed to fuse.

One detail deserves a second look before release: the included angle is not the bevel angle on one face. A 60 degree included V groove has 30 degrees of bevel per plate, while a drawing that says 60 degree bevel describes a 120 degree included angle, which needs far more filler and widens the heat-affected zone. The finishing letter is a routing instruction too: G is grinding, M machining, C chipping, R rolling, H hammering, and each one costs a step.

In sheet metal fabrication below about 3 mm, square groove symbols with a near-zero root opening are common, because the edge cannot carry a meaningful bevel and the material distorts. Above 6 mm, V and bevel grooves take over. Above 20 to 25 mm, U and J preparations keep the groove narrow and cut weld metal volume against a full V.

What Fillet Weld Size Should the Drawing Call Out for a Given Plate Thickness?

For structural steel, AWS D1.1 Table J2.4 sets minimum fillet leg sizes by base metal thickness: 3 mm up to 6 mm thick, 5 mm from 6 to 13 mm, 6 mm from 13 to 19 mm, and 8 mm above 19 mm. Designers size fillets from load, then check the minimum.

The minimum exists because a small fillet on thick plate cools too fast and can crack; it is not a strength recommendation. Size comes from the load path and the effective throat. For an equal-leg 90 degree fillet the throat is 0.707 times the leg, so a 6 mm leg gives about 4.2 mm, an 8 mm leg gives 5.7 mm, and a 10 mm leg gives 7.1 mm. The usual shop-floor mismatch is that the engineer calculates throat and the drawing shows leg.

Weld metal volume rises with the square of the leg, so going from 6 mm to 8 mm adds roughly 78 percent more deposited metal for 33 percent more throat. Oversizing a fillet is one of the most expensive habits in fabrication, and it puts more heat into the part. Metal stamping makes this visible: a stamped bracket has no prepared bevel, so it carries fillet welds on the flange corner, and 1 mm of oversize drafted once is paid for across the whole run.

How Do Welding Symbols Change for Tube and Pipe?

Tube and pipe use the same symbol set, but the joint is curved, the root closes on itself, and access is often one-sided. Expect all-around symbols on every full circumference weld, groove details sized to wall thickness, and a backing ring, consumable insert, or open root callout in the tail or notes.

• Wall thickness sets the preparation. Tube under about 3 mm is often a square groove closed butt welded autogenously; 3 to 10 mm uses a single V or bevel; heavy-wall pipe uses compound bevels or a U preparation.
• Bevel angles follow the code. AWS practice commonly uses a 37.5 degree bevel per face, a 75 degree included angle, while ASME B16.25 specifies 37.5 degrees plus or minus 2.5 degrees per face. Read the included angle against the code in the title block.
• The arrow names the member. On a branch connection the arrow points at the branch, so an arrow-side symbol is the branch-to-header weld and an other-side symbol is the far side of the header wall.
• All-around changes the routing. A full-circumference groove weld on a 200 mm pipe is a different plan than four 50 mm stitches, and the symbol is what tells the planner which applies.
• Socket joints. A fillet symbol with no length means a continuous fillet around the socket, with the size set by the fitting standard rather than the pipe wall.

Orbital welding adds one reading habit. When the tail names an orbital process and the symbol shows a square groove with a consumable insert, the root is closed by the insert, so no backing gas escape path exists unless the drawing provides one. That detail decides purge time and whether the root passes a borescope check.

What Is the Difference Between AWS A2.4 and ISO 2553 Welding Symbols?

AWS A2.4 and ISO 2553 describe the same welds with different conventions. AWS places the weld symbol above or below a single reference line and writes dimensions as bare numbers. ISO 2553 uses a doubled reference line in system A, letter prefixes for dimensions, and a dashed line to mark the far side.

Mixed drawing sets are the practical risk. A European assembly may carry ISO symbols while a subcomponent drawing from a US supplier carries AWS symbols, and the same 6 beside a fillet means different things depending on whether the prefix is z or a. When a package mixes both, state the governing standard in the title block and settle it at drawing review, not at first article.

What Checklist Prevents Misread Weld Symbols?

Run the same ten checks on every symbol: arrow target, side, family, size, length, pitch, groove detail, contour, site condition, and tail reference. Then run the five common mistakes against the finished drawing set. A review at the detail stage costs less than a cut-and-reweld after inspection.

• Arrow tip touches the joint that is welded, not the nearest edge.
• Symbol side matches the intended face, including the root face on butt joints.
• Size is read in the right unit and against the right basis: leg for AWS, z or a for ISO.
• Length and pitch are in the correct order, and pitch is center to center.
• Included angle and bevel angle are not confused.
• Root opening is achievable with the fit-up fixtures on the floor.
• Contour and finishing letter have a routing step and an inspection method.
• All-around and field weld flags are reflected in shipping splits and site access.
• Tail references a WPS that exists and is qualified for the thickness range.
• Symbols on both faces mean two welds, not one weld through both members.

The five mistakes that recur: reading fillet size as throat; reversing length and pitch; treating an omitted groove size as a drafting error instead of complete joint penetration; ignoring the field weld flag until the truck is loaded; and assuming the all-around circle covers both faces of a double-sided detail when it only covers the perimeter. Weld inspection sits under quality assurance, and the drawing check belongs there too, because a symbol that cannot be read consistently will not be welded consistently.

Production welding at YC Prime Precision covers MIG, TIG, spot, and robotic welding on sheet metal parts, machined components, and welded assemblies up to large frame sizes, with weld callouts checked against the drawing and the WPS during first-article inspection. Welding services run from prototype quantities through production runs, and a drawing set sent through the instant quote form comes back with the weld callouts reviewed, not just priced.

Frequently Asked Questions About Welding Symbols

Most welding symbol questions come down to side, size, and the tail. The six answers below cover the triangle, arrow side versus other side, length and pitch, the field weld flag, groove size when it is omitted, and leg-to-throat conversion. Each applies to AWS A2.4 and ISO 2553 drawings unless the convention is noted.

What does the triangle mean on a welding symbol?

A triangle is the fillet weld symbol. Its vertical leg stands on the reference line and the angled leg points toward the arrow. Position above or below the reference line sets which face is welded, and the number at the left gives the leg size in the drawing’s units.

How do I tell the arrow side from the other side?

The arrow side is the face the arrow tip touches. A weld symbol below the reference line applies to that face, and a symbol above the line applies to the opposite face. ISO 2553 system A shows the same distinction with a dashed identification line instead of a symbol placed above the line.

How do I read 50-150 on a welding symbol?

The first number is the weld length and the second is the pitch, the center-to-center distance between welds, in the drawing’s units. So 50-150 means a 50 mm weld every 150 mm, which leaves a 100 mm gap between welds. Pitch is measured center to center, never gap to gap.

What does the flag on a welding symbol mean?

A flag at the junction of the arrow and the reference line marks a field weld, meaning the joint is welded at the site rather than in the shop. It affects shipping splits, site access, and inspection responsibility, so it should be settled at quoting, not on the installation date.

What if a groove weld symbol has no size?

No size on a groove weld symbol means complete joint penetration, provided the joint detail matches the standard preparation. When the designer wants partial penetration, the depth appears at the left of the groove symbol. The omission is intentional, so raising it as a drawing error costs a review cycle.

How do I convert fillet leg to throat thickness?

Multiply the leg length of an equal-leg 90 degree fillet by 0.707. A 6 mm leg gives about 4.2 mm of effective throat, an 8 mm leg gives 5.7 mm, and a 10 mm leg gives 7.1 mm. Design calculations use throat while AWS drawings call out leg, which is where mismatches start. When a weld callout sits next to tight dimensional requirements, pair it with GD&T controls so the drawing states both the joint and the geometry without ambiguity.
